Superheterodyne quad-channel receiver that supports one plug-in memory for each channel
«Robustness and range to welcome you home»
Receivers
BOX M 240
4 memory system
The BOX M 240 receiver uses an independent memory for each output, allowing both common accesses to different installations or four different gate management.
Three security levels
The receiver can be set to comply with one of three security levels: basic (community use), intermediate (private use) and advanced (enterprise use).
High security Evolutive Cryptocode
Encrypted codification with more than 4000 million different combinations guarantees the user's security.
Easy installation management
Programming is done manually or via radio making installation management easier. SMINN tools are designed for this purpose.
Up to 4x2000 transmitters
It is possible to increase the user capacity with plug-in memory cards of 250, 500, 1000 and 2000 users.
Models
| BOX M 240B | 230VAC | 4x35 codes | |
|---|---|---|---|
| BOX M 240 | 230VAC | 4x250 codes | |
| BOX M 240-K5 | 230VAC | 4x500 codes | |
| BOX M 240-1K | 230VAC | 4x1000 codes | |
| BOX M 240-2K | 230VAC | 4x2000 codes | |
| BOX M 244B | 12/24V AC/DC | 4x35 codes | |
| BOX M 244 | 12/24V AC/DC | 4x250 codes | |
| BOX M 244-K5 | 12/24V AC/DC | 4x500 codes | |
| BOX M 244-1K | 12/24V AC/DC | 4x1000 codes | |
| BOX M 244-2K | 12/24V AC/DC | 4x2000 codes |
* Supports removable memories of 250, 500, 1000 and 2000 codes.
